Core Technical Parameters
Door Body Basic Parameters
Dimension Specifications
Standard diameter 3600-4000mm (customizable), display box width usually 300-500mm, single-wing passage width 800-1200mm (sufficient for two people to walk side by side).
Operating Performance
Door opening speed 0.5-0.8m/s (adjustable), sensing delay 0-3 seconds, automatically switches to manual mode when power is lost (push force ≤ 50N, compliant with accessibility standards).
Environmental Adaptability
Suitable temperature range -20℃-50℃ (optional freeze protection configuration for low-temperature areas), wind resistance grade ≤ 8, sealing performance reaches GB/T 7106-2019 “Classification and Testing Methods for Air Tightness, Water Tightness, and Wind Pressure Resistance of Building Windows and Doors” level 6.
Display Box Parameters
Dimensions
Regular internal display space depth 250-400mm, height consistent with the door body (usually 2200-2800mm), can be embedded with LED screens (resolution ≥ 1920×1080).
Functions
Support constant temperature (5℃-30℃ adjustable for sample display), LED lighting (color temperature 3000K-6000K), glass can be treated for anti-glare.
Main Materials
Door Frame Materials
Mainstream Materials
Use 6063-T5 aerospace-grade aluminum alloy, treated with anodizing (film thickness ≥ 15μm) or fluorocarbon spraying (coating thickness ≥ 60μm), resistant to oxidation and corrosion, with a lifespan of up to 15 years.
Special Scenarios
Coastal areas can choose 316L stainless steel frame (resistant to salt spray corrosion), clean areas such as hospitals can choose antibacterial aluminum alloy (antibacterial rate ≥ 99%).
Glass Materials
Door Wing Glass
Double-layer insulating tempered glass (thickness 5+12A+5mm, A is the air layer), light transmittance ≥ 85%, impact resistance meets GB 15763.2-2005 (able to withstand 1040g steel ball impact at 1m height without breaking).
Display Box Glass
Optional double-layer laminated insulating glass (5+0.76PVB+5+12A+5mm, PVB is the laminated layer), no splash risk after breakage, higher safety.
Display Box Internal Materials
Inner Liner
Food-grade ABS plastic sheet (scratch-resistant) or matte stainless steel sheet (easy to clean), colors can be customized (matching architectural style).
Sealing Materials
Use EPDM (triple rubber) rubber strips at the door frame and floor, resistant to aging, strong sealing, reduces energy consumption (30% more energy-efficient than ordinary doors).
Hardware System Features
Drive and Transmission Hardware
Drive Motor
Standard diameter 3600-4000mm (customizable), display box width usually 300-500mm, single-wing passage width 800-1200mm (sufficient for two people to walk side by side).
Transmission Structure
Use high-precision planetary gear reducer (transmission efficiency ≥ 90%), combined with stainless steel main shaft (diameter ≥ 50mm), load-bearing capacity ≥ 800kg, running smoothly without shaking.
Drive and Transmission Hardware
Sensing Devices
Standard micro-wave radar (sensing distance 0.5-3m, able to identify moving targets) + infrared anti-collision sensor (arranged along the edge of the door wing, response time ≤ 0.1 seconds), avoiding injury.
Emergency Hardware
Bottom of the door body has anti-collision strips (force ≥ 50N will automatically reverse operation), top has a manual emergency lock (can be quickly unlocked in case of power failure).
Connection and Fixation Hardware
Connecting parts
304 stainless steel bolts (anti-rust) and cast aluminum hinges (adjustable angle, facilitating installation and calibration) are used. All hardware components are treated with galvanization or passivation (salt spray test ≥ 48 hours, corrosion-resistant).
Display box hardware
The display box door uses a concealed hinge (aesthetically pleasing) and a magnetic lock (light and convenient to operate, with good sealing performance). An adjustable shelf bracket is installed inside (allowing flexible adjustment of the display item height).
