Detailed core parameters
Dimensional parameters
Door opening width (common)
3000mm – 3800mm, customizable up to 5000mm.
Door height (common)
2600mm – 3000mm, maximum up to 3500mm (requires reinforced structure).
Column diameter
Typically 800mm – 1200mm, with the interior capable of integrating access control, lighting, or advertising screens.
Net width of each wing
Approximately 600mm – 900mm, ensuring smooth passage for individuals carrying luggage.
Performance parameters
Rotation speed
0.5 – 1.5 r/min (adjustable), default 1.0 r/min, balancing passage efficiency and safety.
Passage capacity
Approximately 30 – 45 people per minute (calculated based on single-person passage).
Environmental adaptability
-30℃ – 50℃ (anti-freezing motors required in low-temperature areas), wind resistance level ≤ 8.
Power supply and power consumption
AC 220V/380V, standby power consumption ≤ 10W, operating power consumption ≤ 150W.
Main material configuration
Frame material
Mainstream use of 304/316 stainless steel, thickness 1.5 – 2.0mm; for high-end applications, aluminum profiles (surface fluorocarbon spraying, color customization) are available, which are lightweight and corrosion-resistant.
Glass material
Standard single-layer tempered glass (6/8mm), providing sound insulation and heat insulation; for special requirements, laminated tempered glass (anti-shattering and splashing) or Low-E coated glass (enhanced energy-saving) can be selected.
Ceiling and base
Ceiling made of stainless steel plate or aluminum ceiling tiles; base made of stainless steel anti-slip plate, with drainage holes at the bottom (preventing water accumulation and rust).
Features of the hardware system
Drive system
Generally, it is made of high-quality steel, undergoes heat treatment and surface treatment, has good wear resistance and corrosion resistance, can withstand the weight of the door body and the torque during rotation, ensuring smooth door rotation and long service life.
Transmission and support
Without deviation
op equipped with precision bearing group (imported NSK/SKF), load-bearing capacity ≥ 500kg, ensuring long-term rotation without deviation.
Hidden guide wheels
Bottom features hidden guide wheels, fitting the circular track, reducing friction and enhancing sealing.
Dimensional parameters
Infrared anti-squeeze sensors
Infrared anti-squeeze sensors (2 – 4 sets) embedded at the edges of the door wings, immediately stopping rotation upon contact with a person.
Emergency stop button
Emergency stop button + automatic unlocking upon power failure, allowing manual pushing of the door body after power failure (compliant with fire safety regulations).
Sealing accessories
EPDM (Ethylene Propylene Diene Monomer) sealing strips used at the contact points between the door wings and columns, ceiling, and ground, with an air-tightness level ≥ 6, effectively blocking outdoor cold air and dust.
