Detailed parameters
Dimension parameters
Common specifications include inner diameters of 2800mm, 3000mm, and 3200mm (customizable according to actual dimensions).
Passage parameters
The passage capacity of the three-wing manual rotating door can generally reach 600-900 people per hour, depending on the size of the door and the usage scenario.
Material introduction
Frame material
Usually, national standard 6063 T5 aluminum alloy profiles are used, which have the characteristics of light weight, high strength, and corrosion resistance. Some also use high-strength integral steel structure keels, which have high strength and good stability.
Door body material
The door panels are usually made of 8mm thick tempered glass, and the curved walls use 6mm thick curved transparent glass, which has good transparency and safety.
Exterior decorative materials
Stainless steel can be selected, with surface treatments such as grain, satin, sandblasting, and mirror finish, offering a variety of colors; or fluorocarbon spray finish can be chosen, with 78 color options available, and customization is also possible; copper plate finish has two materials, yellow copper and purple copper, and the surface color can be customized.
Sealing materials
The door frame edge is equipped with imported anti-wind brushes, which play a good role in windproof and dustproof.
Hardware Features
Center shaft assembly
Generally, it is made of high-quality steel, undergoes heat treatment and surface treatment, has good wear resistance and corrosion resistance, can withstand the weight of the door body and the torque during rotation, ensuring smooth door rotation and long service life.
Handles
Generally, they are made of stainless steel or other metal materials that match the style of the door body, have a comfortable feel, and are easy to operate. The door lock uses a mechanical door lock, which is safe, reliable, and convenient for maintenance.
