Detailed Parameters
Motor power
Generally 0.25KW, voltage AC 220V 50HZ, rated current <12A, rated speed 1380rad/min, reduction ratio 1:60:6, standard normal speed 4-6 revolutions/min, slow speed for the disabled 1.5-2 revolutions/min.
Material Introduction
Glass material
The door panel glass usually adopts 6mm or 12mm tempered safety glass, the fixed glass of the curved wall is generally 8mm heat-bent tempered glass or 8mm + 1.52 + 8mm laminated heat-bent glass, and the ceiling glass can use 8mm + 1.52 + 8mm laminated tempered glass, which has good light transmission, safety and thermal insulation performance.
Frame material
The frame is generally made of stainless steel, such as 304 stainless steel, which has the characteristics of corrosion resistance and high strength; it can also be made of aluminum alloy profiles, such as national standard 6063 T5 aluminum alloy profiles, which are light in weight, high in strength and easy to process, and the surface can be treated with fluorocarbon spraying, etc., with a variety of colors available for customization.
Hardware Features
Drive system
It adopts well-known brands such as Lenze AC motors, such as AC220V 50HZ 0.25KW motors, equipped with overheat protection and speed feedback devices, stable operation, low noise and long service life.
Control system
Usually equipped with Panasonic programmable logic controller PLC, voltage AC220V, output ±24V, I/O points 14, which can realize functions such as emergency stop, safety protection, start, speed feedback, etc.
Safety protection hardware
The edge of the door wing is usually equipped with non-contact anti-collision sensors. When the moving door panel approaches the pedestrian’s feet, the revolving door immediately slows down and stops; the right side of the entrance and exit columns is equipped with electronic safety edge switches. When pedestrians are squeezed, the door body immediately stops running to prevent injury to pedestrians. It also comes with slow speed and emergency stop buttons for the disabled, etc.
