Detailed Parameters
Operating Performance
Opening speed 0.4 – 0.8 m/s, closing speed 0.3 – 0.7 m/s, adjustable through the controller; opening width 600 – 1800 mm (single door), maximum for double doors up to 3000 mm, meeting the requirements for hospital beds and carts.
Sensing Method
Standard micro-wave radar sensing (detecting distance 0.5 – 5 m, sensing angle 120°), optional infrared beam sensing (clamping error ≤ 5 mm) or foot sensing (suitable for sterile surgical room scenarios).
Environmental Adaptability
Working temperature -10°C – 50°C, humidity ≤ 90% RH (no condensation); equipped with anti-clamping function, when closing encounters resistance (≥ 50 N), it automatically reverses to open, meeting medical safety standards.
Cleanliness Level
Can reach ISO 8 level (10,000-level) cleanliness standard, door gap sealingness ≤ 0.1 m³/(h·m), suitable for clean operating rooms, ICU and other areas.
Core Materials
Door Panel Material
Mainly 304 stainless steel plate (thickness 1.2 – 1.5 mm), corrosion-resistant, easy to clean, can withstand alcohol and chlorine disinfectant wiping; in clean areas, color steel plate (filled with rock wool/polyurethane insulation layer, thermal conductivity ≤ 0.03 W/(m·K)) can be selected, balancing insulation and cleanliness.
Glass Configuration
Windows use 5mm + 5mm laminated tempered glass, light transmittance ≥ 90%, impact resistance ≥ 50 kJ/m², after breaking, there are no sharp fragments, meeting medical safety requirements.
Sealing Materials
Door frame and door panel gaps use silicone rubber sealing strips (Shore hardness 50 ± 5), resistant to aging, resistant to high and low temperatures, no odor during long-term use, ensuring the sealingness of the clean area.
Hardware Features
Driving System
Uses DC brushless motor (power 60 – 120 W), operating noise ≤ 50 dB, service life ≥ 500,000 times; equipped with planetary gear reducer
